Yamaha MGP24X
The MGP24X is Yamaha's 24-channel premium analogue console, with sixteen mic inputs on switchable phantom power and sixteen mono plus four stereo line channels. Routing is generous for an analogue desk: six aux sends, two FX sends, four group buses plus the stereo bus, two matrix outputs and a mono output. Two separate on-board processors handle effects, a REV-X reverb engine and a 16-program SPX engine, and an iPod/iPhone USB port allows playback and control via the MGP Editor app.
Available from Sound Creations Ltd Rwanda in Kigali, with manufacturer warranty and local after-sales support.
Specifications
| Mixing channels | 24 line inputs (16 mono and 4 stereo) |
|---|---|
| Mic inputs | 16 (input HPF 100 Hz, 12 dB/oct) |
| Phantom power | 48 V per channel |
| Groups | 4 GROUP buses + ST bus |
| AUX | 6 AUX sends + 2 FX sends |
| Matrix | 1 matrix out (2 matrix output jacks) |
| On-board processors | FX1 REV-X (8 programs, parameter control), FX2 SPX (16 programs, parameter control) |
| Line inputs / inserts | LINE 16 mono + 4 stereo, CH INSERT 16, RETURN 1 stereo |
| Digital I/O | USB device, iPod / iPhone |
| Main outputs | ST OUT L/R (XLR + phone), MONO OUT (XLR), GROUP OUT 1-4, AUX SEND 1-6, MATRIX OUT 1-2, MONITOR OUT L/R, PHONES |
| Total harmonic distortion | 0.02 % (20 Hz - 20 kHz @ +14 dBu) |
| Frequency response | +0.5 / -1.0 dB, 20 Hz - 20 kHz @ nominal output, 1 kHz |
| Equivalent input noise | -128 dBu |
| Residual output noise | -92 dBu |
| Crosstalk | -74 dB @ 1 kHz |
| Power requirements | 100 - 240 V, 50/60 Hz |
| Power consumption | 86 W max |
| Dimensions (W x H x D) | 819 mm x 169 mm x 565 mm (32.2" x 6.7" x 22.2") |
| Net weight | 15.5 kg (34.2 lb) |
| Talkback | dedicated talkback mic input (XLR) |
Specifications are indicative. Confirm the current datasheet before ordering.
