Yamaha DM3 Standard
The DM3 Standard is Yamaha's most compact digital mixing console, built around a 9-inch multi-touch screen and a single Touch & Turn encoder with an 8+1 fader layout. It handles 22 mixing channels (16 mono, 1 stereo and 2 FX returns) at up to 96 kHz, with 16 mic/line inputs, 8 XLR outputs and 18-in/18-out USB streaming and multitrack recording. It is the non-Dante version of the DM3 series, aimed at small live shows, livestreaming and home or location recording.
Available from Sound Creations Ltd Rwanda in Kigali, with manufacturer warranty and local after-sales support.
Specifications
| Input channels | 16 mono + 1 stereo + 2 FX return |
|---|---|
| Buses | 1 Stereo, 6 Mix, 2 FX, 2 Matrix (supports Input to Matrix), 1 Cue |
| Analog inputs | 16 mic/line (12 XLR + 4 XLR/TRS combo) |
| Analog outputs | 8 (XLR) |
| Dante | not fitted (Standard model) |
| USB audio | 18 inputs / 18 outputs (USB Type-B, USB 2.0) |
| USB TO DEVICE | 1 (USB Type-A), 2-track recording/playback to USB storage |
| Network | 1 (RJ-45) |
| Effects | 18 effects, GEQ on Mix 1-6 and Stereo |
| User interface | 9-inch multi-touch screen, 9 faders (8 channel + 1 main), 1 Touch and Turn encoder |
| Sampling frequency | 96 kHz / 48 kHz |
| Signal delay | less than 1.3 ms (CH INPUT to OMNI OUT, Fs=96 kHz) |
| Frequency response | +0.5 / -1.0 dB, 20 Hz - 20 kHz |
| Total harmonic distortion | less than 0.01 % (20 Hz - 20 kHz @ +4 dBu into 10 kOhm) |
| Dynamic range | 110 dB typ. (DA converter) |
| Power requirements | DC 24 V / 2.5 A via PA-L500 adapter (100-240 V, 50/60 Hz) |
| Power consumption | 43 W |
| Dimensions (W x H x D) | 320 mm x 140 mm x 455 mm |
| Net weight | 6.5 kg (14.3 lb) |
| Operating temperature | 0 to 40 degrees C |
Specifications are indicative. Confirm the current datasheet before ordering.
