Yamaha TF5 Digital Mixing Console
The Yamaha TF5 is the largest console in the TF series of digital mixers, built around Yamaha's TouchFlow Operation touchscreen interface. It provides 48 input mixing channels and 33 motorised faders, with 32 onboard recallable D-PRE mic/line preamps and features such as GainFinder, 1-knob EQ and 1-knob COMP to speed up setup. A built-in 34 x 34 USB 2.0 interface handles multitrack recording, and an expansion slot accepts the NY64-D Dante card.
Available from Sound Creations Ltd Rwanda in Kigali, with manufacturer warranty and local after-sales support.
Specifications
| Motor faders | 33 (32 channels + 1 master) |
|---|---|
| Input mixing channels | 48 (40 mono + 2 stereo + 2 return) |
| Buses | 20 Aux (8 mono + 6 stereo) + Stereo + Sub |
| DCA groups | 8, with Roll-out |
| Analog inputs | 32 mic/line XLR/TRS combo + 2 stereo line (RCA pin) |
| Analog outputs | 16 XLR |
| Mic preamps | Recallable D-PRE, max gain +66 dB, load impedance 7.5 k-ohm |
| Input sensitivity | -82 dBu (61.6 uV) to -42 dBu (6.16 mV) max before clip; nominal -62 dBu |
| USB recording | 34 x 34 channels, 24-bit, via USB 2.0 (Type B, TO HOST) |
| USB storage | 2 x 2 record/playback via USB storage device (MP3/WAV playback, WAV record) |
| Onboard processing | 8 effects + 10 GEQ |
| Expansion | 1 slot for NY64-D Dante audio interface card |
| Apps | TF Editor, TF StageMix, MonitorMix; Nuendo Live included |
| Dimensions (W x H x D) | 866 x 225 x 599 mm |
| Weight | 20 kg |
Specifications are indicative. Confirm the current datasheet before ordering.
